AOC 21.5" Full HD Monitor | 22B2H-EU
AOC 21.5" Full HD Monitor | 22B2H-EU
AOC's 22B2H brings together a minimal 3 side frameless panel with VGA & HDMI connectivity showcasing modern design whiel providing sharp Full HD quality graphics. Enjoy hours of work or gaming thanks to LowBlue light and FlickerFree technology as well as a wide viewing angle to provide comfort and no headaches.
Features
Frameless Design - Besides looking modern and attractive, frameless designs enable seamless multi-monitor setups. Your cursor/windows will not be lost anymore in the dark abyss of bezels, when many displays are placed side by side.
FHD Resolution - Want to watch a Blu-ray movie in full quality, enjoy games in high resolution or read crisp text in office applications? Thanks to its Full HD resolution of 1920 x 1080 pixels, this monitor lets you do just that. Whatever you are viewing, with Full HD it will be displayed in rich detail without requiring a high-end graphics card or consuming a lot of your system’s resources.
VA Panel - VA Panels (Vertical Alignment) display deeper blacks and a high contrast for extra vivid and bright images.
HDMI - (High-Definition Multimedia Interface) is supported by the current gaming consoles, current GPUs, set-top boxes, supporting the HDCP digital content protection system. HDMI 1.3-1.4b versions support up to 144 Hz refresh rate@1080p and 75 Hz@1440p, while HDMI 2.0-2.0b versions support 240Hz@1080p, 144Hz@1440p and 60 Hz@2160p (4K).
Low Blue Light - AOC Lowblue Light protects you from harmful blue light which, during long sessions, has been shown to cause eye strain, headaches, and sleeping disorders. Our Lowblue Light feature reduces the harmful wavelengths emitted without sacrificing color composition, setting the experience free from the worry of eye damage.
Flicker Free - AOC Flicker-Free Technology utilises a DC (Direct Current) backlight panel, reducing flickering light levels. With eye strain and fatigue absolutely minimized, feel free to enjoy those long, intense gaming sessions in comfort!
Specifications
Display:
- Display diagonal: 54.6 cm (21.5´´)
- Display brightness (typical): 200 cd/m²
- Display resolution: 1920 x 1080 pixels
- Native aspect ratio: 16:9
- Response time: 4 ms
- HD type: Full HD
- Display technology: LED
- Backlight type: W-LED
- Display surface: Matt
- Screen shape: Flat
- Supported graphics resolutions: 1280 x 720 (HD 720),1280 x 768 (WXGA),1920 x 1080 (HD 1080)
- Supported video modes: 720p,768p,1080p
- Aspect ratio: 4:3,16:9
- Contrast ratio (typical): 3000:1
- Contrast ratio (dynamic): 20000000:1
- Maximum refresh rate: 75 Hz
- Viewing angle, horizontal: 178°
- Viewing angle, vertical: 178°
- Display number of colours: 16.78 million colours
- Panel type: VA
- Pixel pitch: 0.2482 x 0.2482 mm
- Horizontal scan range: 30 - 83 kHz
- Vertical scan range: 50 - 76 Hz
- Viewable size, horizontal: 47.7 cm
- Viewable size, vertical: 26.8 cm
- Colour depth: 8 bit
- RGB colour spaces: RGB
- sRGB coverage (typical): 98%
- NTSC coverage (typical): 73%
- Adobe RGB coverage: 77%
Performance:
- NVIDIA G-SYNC: No
- AMD FreeSync: No
- Flicker-free technology: Yes
- Low Blue Light technology: Yes
Multimedia:
- Built-in speaker(s): No
- Built-in camera: No
Design:
- Market positioning: Business
- Energy Star certified: Yes
- Frameless design: Yes
- Detachable stand: Yes
- Certification: TÜV Bauart, CE, FCC, GOST, ISO
Ports & interfaces:
- Built-in USB hub: No
- VGA (D-Sub) ports quantity: 1
- DVI port: No
- HDMI: Yes
- HDMI ports quantity: 1
- HDMI version: 1.4
- Audio input: No
- Headphone out: Yes
- Headphone outputs: 1
- Headphone connectivity: 3.5 mm
- DC-in jack: Yes
Ergonomics:
- Panel mounting interface: 100 x 100 mm
- Cable lock slot: Yes
- Cable lock slot type: Kensington
- VESA mounting: Yes
- Height adjustment: No
- Tilt adjustment: Yes
- Tilt angle range-5 - 21.5°
- On Screen Display (OSD): Yes
- On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, SER
- Number of OSD languages: 16
- Plug and Play: Yes
Power:
- Energy efficiency class: B
- Annual energy consumption: 30 kWh
- Power consumption (typical): 18 W
- Power consumption (standby): 0.3 W
- Power consumption (off): 0.3 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- External power adapter: Yes
- Energy efficiency scale: A++ to D
Weight & dimensions:
- Width: 492.8 mm
- Depth: 36.2 mm
- Height: 292.7 mm
- Weight: 2.1 kg
- Width (with stand): 492.8 mm
- Depth (with stand): 162.9 mm
- Height (with stand): 388.1 mm
Packaging data:
- Stand included: Yes
- Cables included: HDMI
- HDMI cable length: 1.8 m
- Power adapter included: Yes
- Package width: 550 mm
- Package depth: 120 mm
- Package height: 370 mm
- Package weight: 3.5 kg
- Package type: Box
- Display diagonal: 54.6 cm (21.5´´)
- Display brightness (typical): 200 cd/m²
- Display resolution: 1920 x 1080 pixels
- Native aspect ratio: 16:9
- Response time: 4 ms
- HD type: Full HD
- Display technology: LED
- Backlight type: W-LED
- Display surface: Matt
- Screen shape: Flat
- Supported graphics resolutions: 1280 x 720 (HD 720),1280 x 768 (WXGA),1920 x 1080 (HD 1080)
- Supported video modes: 720p,768p,1080p
- Aspect ratio: 4:3,16:9
- Contrast ratio (typical): 3000:1
- Contrast ratio (dynamic): 20000000:1
- Maximum refresh rate: 75 Hz
- Viewing angle, horizontal: 178°
- Viewing angle, vertical: 178°
- Display number of colours: 16.78 million colours
- Panel type: VA
- Pixel pitch: 0.2482 x 0.2482 mm
- Horizontal scan range: 30 - 83 kHz
- Vertical scan range: 50 - 76 Hz
- Viewable size, horizontal: 47.7 cm
- Viewable size, vertical: 26.8 cm
- Colour depth: 8 bit
- RGB colour spaces: RGB
- sRGB coverage (typical): 98%
- NTSC coverage (typical): 73%
- Adobe RGB coverage: 77%
Performance:
- NVIDIA G-SYNC: No
- AMD FreeSync: No
- Flicker-free technology: Yes
- Low Blue Light technology: Yes
Multimedia:
- Built-in speaker(s): No
- Built-in camera: No
Design:
- Market positioning: Business
- Energy Star certified: Yes
- Frameless design: Yes
- Detachable stand: Yes
- Certification: TÜV Bauart, CE, FCC, GOST, ISO
Ports & interfaces:
- Built-in USB hub: No
- VGA (D-Sub) ports quantity: 1
- DVI port: No
- HDMI: Yes
- HDMI ports quantity: 1
- HDMI version: 1.4
- Audio input: No
- Headphone out: Yes
- Headphone outputs: 1
- Headphone connectivity: 3.5 mm
- DC-in jack: Yes
Ergonomics:
- Panel mounting interface: 100 x 100 mm
- Cable lock slot: Yes
- Cable lock slot type: Kensington
- VESA mounting: Yes
- Height adjustment: No
- Tilt adjustment: Yes
- Tilt angle range-5 - 21.5°
- On Screen Display (OSD): Yes
- On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, SER
- Number of OSD languages: 16
- Plug and Play: Yes
Power:
- Energy efficiency class: B
- Annual energy consumption: 30 kWh
- Power consumption (typical): 18 W
- Power consumption (standby): 0.3 W
- Power consumption (off): 0.3 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- External power adapter: Yes
- Energy efficiency scale: A++ to D
Weight & dimensions:
- Width: 492.8 mm
- Depth: 36.2 mm
- Height: 292.7 mm
- Weight: 2.1 kg
- Width (with stand): 492.8 mm
- Depth (with stand): 162.9 mm
- Height (with stand): 388.1 mm
Packaging data:
- Stand included: Yes
- Cables included: HDMI
- HDMI cable length: 1.8 m
- Power adapter included: Yes
- Package width: 550 mm
- Package depth: 120 mm
- Package height: 370 mm
- Package weight: 3.5 kg
- Package type: Box
| Colour: | Black |
|---|
